Appearance
Scenarios
Fleets
Auto Repair Shop
Auto Dealership
Features
Rapid Charging
- Swift and Efficient: PIKKA DC Rover 30kW ensures fast and effective charging.
- Double the Power: Dual-ports deliver up to 30kW, allowing sequential charging for two vehicles.
Compact Power, Anywhere You Need
- Space-Efficient Design: Ultra-compact size with significant DC power.
- Versatile Installation: Flexible options for fixed or mobile positioning.
Efficiency in Every Minute
- Time-Saving: A 30-minute charge provides over 50 miles of range.
- Maximize Uptime: Keep moving with minimal downtime during charging sessions.
Cost-Effective Solution
- Smart Investment: Low installation costs for a faster ROI.
- Reduced Capital Expenditure: Minimize operator expenses with the DC Compact's cost-effective design.
Specifications
| DC Output Connection | |
| Charging mode | Mode 4: CCS1 |
| Charging mode | 30kW |
| Output voltage | 150-1000V CCS1: 80A; |
| Max output current Number of outputs | 2*CCS1 |
| Peak efficiency | ≥95% |
|
AC Input Connection |
|
|
Earthing system |
3P, PE (No neutral) |
|
Input voltage |
3-phase 480V AC+10% |
|
Input frequency |
50/60Hz |
|
Power factor |
≥0.99 |
|
Harmonic distortion (THDi) |
≤5% |
|
General Characteristics |
|
|
Enclosure rating |
IP54 |
|
Operating altitude |
2000m |
|
Operating temperature range |
-22℉ ~ +131℉ (-30℃ ~ +55℃) |
|
Storage temperature range |
-40℉ ~ +158℉ (-40℃ ~ +70℃) |
|
Mounting |
Pedestal or wheels&Wall-Mounting |
|
Dimensions (H×W×D) |
H 860 x W500 x D370mm (Chassis included, casters not included) |
|
Screen type |
7 inch LCD touch screen |
|
Cable length |
5m standard |
|
User Interface |
|
|
Status indication |
LCD/APP |
|
User interface |
Charge APP |
|
Connectivity |
4G, Ethernet ,Wi-Fi&Bluetooth(Optional) |
|
Communication protocols |
OCPP 1.6J (Can be upgraded to OCPP 2.0.1 later) |
|
User authentication |
APP, RFID card, Credit card (Optional) |
|
Software Update Software update |
OTA updates via web portal |
|
Certification and Standards |
|
|
Safety and compliance |
UL 2202, UL 2231-1, UL 2231-2 15118 |
|
EMC compliance |
FCC 15 Class A |
|
Warranty |
12 months, warranty extension possible |
